| Resistors |
Resistance value, tolerance, power rating, temperature coefficient, voltage rating, package size, and pulse capability.
|
Select a power rating at least 2 times the calculated steady-state dissipation unless the thermal design requires a different value.
|
Measure resistance at room temperature; perform temperature-rise testing at the maximum expected operating load; inspect solder joints and package condition.
|
Resistance remains within the specified tolerance after testing; surface temperature remains below the component and PCB thermal limits; no visible cracking or discoloration.
|
Schematic, bill of materials, power-dissipation calculation, derating analysis, approved footprint, and inspection record.
|
| Capacitors |
Capacitance, voltage rating, dielectric type, equivalent series resistance, ripple-current rating, aging behavior, polarity, and DC-bias stability.
|
Use a voltage rating with sufficient margin above the highest continuous and transient voltage; account for capacitance loss under DC bias for ceramic capacitors.
|
Measure capacitance and leakage current; test ripple-current heating; perform dielectric withstand or insulation-resistance testing where applicable; verify polarity.
|
Capacitance and leakage current remain within the specified limits; no bulging, venting, cracking, excessive heating, or polarity-related damage occurs.
|
Capacitor specification, bias and temperature derating data, ripple-current calculation, polarity marking, and incoming inspection criteria.
|
| Inductors |
Inductance, saturation current, rated current, direct-current resistance, magnetic shielding, temperature rise, and switching-frequency suitability.
|
Keep peak operating current below the specified saturation-current limit, with additional margin for startup, load steps, and tolerance.
|
Measure inductance and direct-current resistance; apply maximum load and transient current; monitor inductance reduction and temperature rise.
|
Inductance remains adequate during peak current; temperature stays within the approved limit; converter output remains stable without abnormal acoustic or electrical behavior.
|
Magnetic-component calculation, saturation-current assessment, thermal test results, layout recommendation, and approved part specification.
|
| Diodes and Rectifiers |
Reverse-voltage rating, forward current, surge current, forward voltage, reverse-recovery behavior, leakage current, and thermal resistance.
|
Select a reverse-voltage rating above the maximum repetitive and transient reverse voltage; verify surge-current capability for inrush and fault conditions.
|
Measure forward voltage and reverse leakage; test repetitive and non-repetitive surge conditions; verify thermal performance at maximum current.
|
Reverse leakage and forward voltage remain within specification; no breakdown, overheating, or abnormal waveform is observed.
|
Rectifier calculations, transient analysis, thermal design, polarity information, surge-test record, and layout clearance review.
|
| MOSFETs and Transistors |
Drain-source or collector-emitter voltage, continuous and pulsed current, on-state resistance, gate charge, switching speed, safe operating area, and thermal resistance.
|
Apply voltage, current, and junction-temperature derating based on the worst-case operating condition; include switching and conduction losses in the thermal model.
|
Perform static parameter checks, switching-waveform analysis, load-step testing, short-duration overload testing where applicable, and thermal imaging.
|
Voltage and current overshoot remain controlled; switching losses match the design estimate; junction-temperature calculations and measured temperatures remain within limits.
|
Power-loss calculation, gate-drive analysis, safe-operating-area review, thermal model, oscilloscope captures, and protection-circuit validation.
|
| Voltage Regulators and Power Modules |
Input-voltage range, output accuracy, load-transient response, maximum output current, dropout voltage, efficiency, ripple, protection features, and thermal limits.
|
Verify operation across the full input, output-load, ambient-temperature, and component-tolerance ranges; avoid operating continuously at the absolute maximum rating.
|
Test line regulation, load regulation, startup, shutdown, short circuit, current limit, thermal shutdown, ripple, and load-transient response.
|
Output voltage, ripple, transient recovery, current limit, and thermal behavior meet the product requirements across the defined operating range.
|
Power-tree diagram, efficiency data, stability analysis, recommended layout, compensation values, oscilloscope records, and protection-test report.
|
| Operational Amplifiers and Analog ICs |
Supply range, input common-mode range, output swing, offset voltage, input bias current, gain-bandwidth product, slew rate, noise, and stability.
|
Keep signal levels inside the valid common-mode and output ranges; provide bandwidth and slew-rate margin for the fastest expected signal.
|
Measure gain, offset, noise, bandwidth, phase margin or stability behavior, output swing, and response to capacitive or variable loads.
|
Gain and offset meet the error budget; output remains stable under the specified load; noise and bandwidth satisfy system-level requirements.
|
Error-budget calculation, signal-integrity analysis, simulation files, test schematic, measurement setup, and calibration information.
|
| Microcontrollers and Digital ICs |
Supply voltage, clock accuracy, operating temperature, I/O thresholds, drive current, memory capacity, boot behavior, package, and interface requirements.
|
Check I/O current, clock tolerance, memory utilization, and thermal performance against worst-case conditions; provide noise and reset margin.
|
Perform power-on-reset, brownout, clock, memory, I/O loading, interface timing, electromagnetic susceptibility, and firmware stress testing.
|
The device starts reliably, meets timing requirements, maintains valid logic levels, recovers from reset and brownout conditions, and completes the required software tests.
|
Pin-mapping table, timing budget, memory map, firmware revision, programming procedure, reset strategy, and interface-test results.
|
| Connectors and Terminals |
Contact count, current rating, voltage rating, pitch, mating cycles, contact resistance, locking method, wire or PCB compatibility, and environmental rating.
|
Use current and voltage ratings with margin for ambient temperature, grouping, vibration, and expected contact degradation.
|
Measure contact resistance; perform insertion and withdrawal cycling, current heating, vibration, retention, and dielectric-strength testing when required.
|
Contact resistance remains stable; connector temperature stays within limits; terminals do not loosen, deform, or disconnect under defined mechanical and electrical stresses.
|
Connector drawing, pinout, mating specification, mechanical keep-out area, torque or retention requirements, and assembly inspection record.
|
| Crystals and Oscillators |
Nominal frequency, frequency tolerance, stability over temperature, load capacitance, startup time, drive level, aging, and supply requirements.
|
Ensure the total frequency error budget includes initial tolerance, temperature stability, aging, supply variation, and load-capacitance tolerance.
|
Measure startup time, frequency accuracy, frequency drift over temperature, supply sensitivity, and clock behavior during reset and load changes.
|
Startup is reliable; frequency remains within the system timing budget; drive level and oscillator waveform remain within the specified limits.
|
Frequency error budget, load-capacitance calculation, oscillator layout guidance, startup measurements, and environmental test results.
|
| Fuses and Resettable Protection Devices |
Normal current, voltage rating, interrupt rating, time-current characteristic, temperature derating, resistance, and reset behavior.
|
Ensure the device carries the maximum continuous current without nuisance operation while interrupting the defined fault current safely.
|
Test normal-load heating, overload response, short-circuit interruption, repeated-trip behavior, and recovery after fault removal where applicable.
|
The device does not trip during normal operation, limits or interrupts the fault as intended, and does not create unsafe temperature or arc conditions.
|
Protection coordination study, fault-current estimate, time-current curve, safety-clearance review, and fault-test report.
|
| Optocouplers and Digital Isolators |
Isolation voltage, working voltage, creepage, clearance, propagation delay, common-mode transient immunity, insulation type, and temperature range.
|
Maintain the required isolation distance and voltage margin for the intended pollution environment and transient category.
|
Perform isolation withstand, insulation-resistance, propagation-delay, common-mode transient, and input-to-output functional tests.
|
Isolation remains intact; insulation resistance and timing meet requirements; no false switching occurs during defined common-mode transients.
|
Isolation diagram, creepage and clearance review, insulation-test record, safety classification, PCB layout inspection, and interface timing report.
|
| Thermistors and Temperature Sensors |
Measurement range, accuracy, response time, resistance or output characteristic, self-heating, placement, and calibration requirements.
|
Select a measurement range that covers all expected temperatures and includes tolerance, self-heating, and calibration error.
|
Compare readings against a calibrated reference at multiple temperatures; test response time, self-heating, open-circuit, and short-circuit detection.
|
Temperature error remains within the system limit; response time is adequate; sensor faults are detected or handled safely.
|
Sensor curve or transfer function, calibration procedure, placement drawing, error budget, diagnostic thresholds, and test records.
|
| PCB Footprints and Assembly Compatibility |
Land pattern, pad dimensions, courtyard, solder-mask openings, stencil aperture, component height, polarity marking, and manufacturing process compatibility.
|
Use a controlled footprint library and review package tolerances, placement capability, solder-joint geometry, and inspection access.
|
Conduct design-rule checking, assembly trial, solder-joint inspection, dimensional inspection, rework assessment, and thermal-cycle evaluation where required.
|
Components can be placed and soldered consistently; solder joints meet the applicable workmanship criteria; no clearance, polarity, or rework issue is identified.
|
Approved footprint, 3D model, assembly drawing, stencil data, placement file, inspection criteria, and engineering-change history.
|
| Environmental and Reliability Validation |
Operating temperature, storage temperature, humidity, vibration, shock, corrosion exposure, electrical stress, service life, and maintenance conditions.
|
Define operating and storage limits from the complete system environment rather than relying only on individual component ratings.
|
Perform temperature cycling, damp-heat or humidity testing, vibration, mechanical shock, electrical endurance, and post-test functional inspection as applicable.
|
The board remains functional and safe throughout testing; measured performance stays within limits; no unacceptable cracking, corrosion, delamination, or parameter drift occurs.
|
Environmental profile, test plan, sample identification, pre- and post-test measurements, failure analysis, corrective actions, and final validation report.
|
